Vulcanized Clamping Heads (SCV)
Total Views |
- Made out of hardened & ground alloy steel segments, held together by rubber webs.
- Best run out accuracy and rigidity
- True parallel / line contact clamping.
- Available from dia5mm up to dia100mm depending on the basic size.
- Quick change with manual changing device type MDC in less than 15 Seconds
- Available in serrated version for gripping raw parts or smooth version for eliminating clamping marks on finished parts
- Special holding profiles can be made as per customer requirement to clamp odd shaped components.
- Toughened clamping heads are available for in-situ boring with the help of master ring.
- The coolant and cutting oil resistant rubber imparts a long service life
- Vibration dampening for more stable metal cutting conditions.
#Technical specs are subject to change without notice due to continual improvement.
